JUMAO JM-P50A POC Portable Oxygen Concentrator (Pulse Dose)
Specification
|
Model |
JM-P50A |
|
Machine with Battery |
With 8 Core Battery |
|
Oxygen Concentration |
≥90% |
|
Noise dB(A) |
≤50 |
|
Power (VA) |
90 |
|
N.W. (Kg) |
2.16 |
|
Oxygen Delivery Setting |
1-6 |
|
Max. Oxygen Output (ml/Min) |
1470 |
|
Size(cm) |
18.5*8.8*21 |
|
Battery Run Time (Hour) |
5Hour@2setting |
|
Battery Charge Time (Hour) |
3 |
|
Model |
JM-P50A |
|
Machine with Battery |
With 16 Core Battery |
|
Oxygen Concentration |
≥90% |
|
Noise dB(A) |
≤50 |
|
Power (VA) |
90 |
|
N.W. (Kg) |
2.56 |
|
Oxygen Delivery Setting |
1-6 |
|
Max. Oxygen Output (ml/Min) |
1470 |
|
Size(cm) |
18.5*8.8*23.8 |
|
Battery Run Time (Hour) |
10Hour@2setting |
|
Battery Charge Time (Hour) |
6 |
Features
✭Different flow setting
It is three different settings with the higher numbers providing a greater amount of oxygen from 210ml to 630ml per minute.
✭Multiple Power Options
It is capable of operating from three different power supply: AC power, DC power, or rechargeable battery
✭Battery runs longer time
5 hours possible for double battery pack.
Simple Interface for easy Use
Made to be user-friendly, the controls can be located on the LCD screen at the top of the device. The control panel features an easy-to-read battery status gauge and liter flow controls、 Battery status indicator 、Alarm indicators
Multiple Alarm reminding
Audible and Visual alerts for Power Failure, Low Battery, Low Oxygen Output, High Flow/Low Flow, No Breath Detected in PulseDose Mode, High Temperature, Unit Malfunction to ensure the safety of your using.
Carry Bag
It can be placed in its carry bag and slung over your shoulder to be used throughout the day or when travelling.You can access the LCD screen and controls at all times, making it easy to check the battery life or change your settings whenever necessary.
FAQ
1.Are You The Manufacturer ? Can You Export It Directly ?
Yes ,we are manufacturer with around 70,000 ㎡ production site.
We have been exported the goods to oversea markets since 2002. we can provide most documentation including ISO9001, ISO13485, FCS, CE, FDA, Certificates of Analysis / Conformance; Insurance; Origin, and other export documents where required.
2.What Is Pulse Dose Technology ?
Our POC has two modes of operation : a standard mode and a pulse dose mode .
When the machine is on but you don’t breath it in a long time , the machine will automatically adjust to a fixed oxygen discharge mode : 20 times/Min. Once you start to breathe , the oxygen output of the machine is completely adjusted according to your breathing rate, up to 40 times/Min. The pulse dose technology would detect your breathing rate and temporarily increase or decrease your flow of oxygen.
3.Can I Use it When It's In Its Carrying Case?
It can be placed in its carry case and slung over your shoulder to be used throughout the day or when travelling. The shoulder bag is even designed so that you can access the LCD screen and controls at all times, making it easy to check the battery life or change your settings whenever necessary.
4. Are Spare Parts and Accessories Available for the POC?
When you place an order , you can order more spare parts at the same time .such as Nasal oxygen cannula ,Rechargeable Battery,External Battery Charger, Battery and Charger Combo Pack ,Power Cord with Car Adaptor
Company Profile
Jiangsu Jumao X-Care Medical Equipment Co., Ltd. is situated in the Danyang Phoenix Industrial Zone, Jiangsu Province. Established in 2002, the company boasts a fixed asset investment of 170 million yuan, spanning an area of 90,000 square meters. We proudly employ over 450 dedicated staff members, including more than 80 professional and technical personnel.
Production Line
We have invested significantly in new product research and development, securing many patents. Our state-of-the-art facilities include large plastic injection machines, automatic bending machines, welding robots, automatic wire wheel shaping machines, and other specialized production and testing equipment. Our integrated manufacturing capabilities encompass precision machining and metal surface treatment.
Our production infrastructure features two advanced automatic spraying production lines and eight assembly lines, with an impressive annual production capacity of 600,000 pieces.
Product Series
Specializing in the production of wheelchairs, rollators, oxygen concentrators, patient beds, and other rehabilitation and health care products, our company is equipped with advanced production and testing facilities.
